Cummins Engine Fire Pump Set

Flow: 30-9000gpm

Head: 1-70m

Power: 3-355KW

Frequency: 50 Hz or 60 Hz

If you want to get more product information please contact us!

Send E-mail Get Price

Product Introduction
Structure
Applications
Technical Data

This diesel fire pump system consist of Cummins Engine diesel fire pump, jockey pump and control panel.

1. Diesel engine pump, can use single stage pump, horizontal split case pump, end suction pump, multistage pump, material can be cast iron, stainless steel, and bronze impeller , with fuel tank, water tank，fan, control box
2. Jockey pump, horizontal or vertical, capacity will be small, but head should be higher than electric and diesel engine pump
Jockey material casing: cast iron, shaft and impeller: SS304
3. Control panel: Auto Control of diesel engine pump and Jockey Pump with overload, over current protection
4. Accessories: check valve, gate valve, pressure vessel, generally 0.6mpa, 1.0mpa, 1.6mpa, Pressure Gauge, Pressure Sensor, Common Pipe for Suction and Discharge, Flexible Joints and Flanges, Common Base plant

Model	Pump				Diesel Engine			Jockey Pump
	Flow		Head	Pressure	Model	Power	Diesel Engine	Model	Head	Power
	M3/h	GPM	bar	Pis	Model	kW	Diesel Engine	Model	kW	L
DJ25/3	5.6	25	3	44	BTI40/40-171	4	173F	CDL2-5	3.7	0.55
DJ25/4	5.6	25	4	58	BTI40/40-171	4	173F	CDL2-6	4.5	0.75
DJ25/5	5.6	25	5	73	BTI40/40-171	4	173F	CDL2-7	5.2	0.75
DJ25/6	5.6	25	6	87	BTI40/40-171	4	173F	CDL2-9	6.7	1.1
DJ25/7	5.6	25	7	102	BTI50/50-198	6.7	186FA	CDL2-10	7.5	1.1
DJ25/8	5.6	25	8	116	BTI50/50-198	6.7	186FA	CDL2-12	9	1.5
DJ25/9	5.6	25	9	131	1.5GCx3	8.6	192F	CDL2-13	9.7	1.5
DJ25/10	5.6	25	10	145	1.5GCx4	9.2	195F	CDL2-14	10.5	1.5
DJ25/11	5.6	25	11	160	1.5GCx4	9.2	195F	CDL2-15	11.2	1.5
DJ25/12	5.6	25	12	174	1.5GCx5	10.2	1100F	CDL2-17	12.7	2.2
DJ30/3	6.9	30	3	44	BTI40/40-171	4	173F	CDL2-5	3.7	0.55
DJ30/4	6.9	30	4	58	BTI40/40-171	4	173F	CDL2-6	4.5	0.75
DJ30/5	6.9	30	5	73	BTI40/40-171	4	173F	CDL2-7	5.2	0.75
DJ30/6	6.9	30	6	87	BTI40/40-171	4	173F	CDL2-9	6.7	1.1
DJ30/7	6.9	30	7	102	BTI50/50-198	6.7	186FA	CDL2-10	7.5	1.1
DJ30/8	6.9	30	8	116	BTI50/50-198	6.7	186FA	CDL2-12	9	1.5
DJ30/9	6.9	30	9	131	1.5GCx3	8.6	192F	CDL2-13	9.7	1.5
DJ30/10	6.9	30	10	145	1.5GCx4	9.2	195F	CDL2-14	10.5	1.5
DJ30/11	6.9	30	11	160	1.5GCx4	9.2	195F	CDL2-15	11.2	1.5
DJ30/12	6.9	30	12	174	1.5GCx5	10.2	1100F	CDL2-17	12.7	2.2
至
DJ100/10	22.7	100	10	145	D25-30x4	20	295F	CDL2-14	10.5	1.5
DJ100/11	22.7	100	11	160	D25-30x4	20	295F	CDL2-15	11.2	1.5
DJ100/12	22.7	100	12	174	D25-30x4	20	295F	CDL2-17	12.7	2.2
